Steel structure platform of steel structure engineering

1、 Layout of steel structure platform

       1.Determine the platform structure size, elevation and lattice beam column layout. In addition to meeting the use requirements, the layout of beams and columns should also consider the equipment load on the platform and other large concentrated load locations and the hanging of large-diameter industrial pipelines;

       2.The layout of the structural platform should strive to achieve reasonable economy and direct transmission.The arrangement of grillage should adapt to its span.When the span of the beam is large, the spacing should also be increased.In order to achieve better economic benefits, it is necessary to make full use of the allowable span slab and arrange the lattice beam reasonably.

       3.Meet the process operation requirements and ensure the safety of transportation operation.Generally speaking, the net height should not be less than 1.8m, and the protective railing should be set at the platform and the height of the railing is generally 1m.When the platform height is greater than 2m, the riser shall be set under the protective railing.The platform shall be equipped with up and down ladders, and the width of the ladders shall not be less than 600mm.

2、 Composition and classification of construction platform

       1.Platform structure usually consists of planking, primary and secondary beams, columns, columns, ladders, railings, etc.

       2.Classification: according to the requirements, it can be divided into indoor and upper platform, bearing static load and dynamic load platform, production auxiliary platform and medium and heavy operation platform.The structure of the platform can also be divided into:

       3, are independent platforms.For the platform of high-power or heavy equipment, it should be separated from the plant column and directly supported on the independent column.Click here to download construction technical data for free

       4.The platform directly placed on the three legs or legs of the workshop column is usually a safe passage or a simple medium operation platform.

       5.One side is supported on the column or wall of the building, and the other side is supported by an independent column.

       6, large equipment support platform./7 steel structure platform is an independent system in steel structure, which can be used indoor and outdoor.According to the established standards and requirements, the construction technology is reasonably arranged, and the steel structure platform construction meets the application requirements.
