Composition and description of drive in shelf

1. back pulling: increase the overall stability of the shelf.

2. diagonal bracing: form column plate with column and cross bracing to increase the strength and stability of column plate.

3. cross brace: form column plate with column and diagonal brace to increase the strength and stability of column plate.

4.Top pull: increase the overall stability of the shelf.

5. bottom corner: this part is connected with the column, fixed on the ground, and plays a supporting role.

6. crossbeam: horizontal connection of shelf.

7.Shelf: it is connected with bracket, and the cargo tray is placed on the piece.

8. column: main support in vertical direction, mainly for supporting.

9. single corbel: connected with column and supported by cantilever.

10. double corbel: it is connected with the column, and the cantilever supports the goods.



Drive in shelf design elements:

1. weight of goods (including pallets);

2, pallet size and cargo size (width × depth × height);

3. construction of storage area;

4.    Model and lifting height of forklift;

5. direction and requirements for goods in and out of warehouse
