Hongjishunda steel structure company points out that nowadays, many production-oriented enterprises adopt steel structure engineering in their workshops and warehouses. Compared with traditional building structure workshops, the processing and installation period of steel structure engineering is relatively short, and the cost is reasonable and recyclable. This can undoubtedly save costs for production-oriented enterprises and provide power for the development of enterprises, which becomes steel structure engineering.One of the important reasons that it has been widely used in China is that the processing and installation of steel structure engineering is different from the production of ordinary building structure workshop.So, what is the construction and installation process of steel structure engineering?Let the three-dimensional steel structure company construction personnel for your simple explanation and analysis!

Steel structure engineering construction

Generally speaking, the large construction process mainly includes the following five points: 1. Hoisting of main structure; 2. Installation of secondary structure; 3. Installation of roof panel and insulation layer; 4. Maintenance and installation of wall; 5. Detailed structure.The following is a detailed analysis and introduction by Hebei steel structure company – Hongjishunda steel structure company

 　　1Hoisting of main structure: splicing steel beam on the ground, erecting steel column, hoisting steel beam, connecting secondary structure, correcting main structure deviation, installing crane beam (optional), hoisting interlayer (optional), coating fire retardant coating.Main quality control: the main structure deviation shall meet the specification and design requirements, and the initial and final tightening of high-strength bolts shall meet the requirements.

 　　2Secondary structure installation: roof wall purlin, roof wall support, flange support, etc.

 　　3Installation of roof panel and thermal insulation layer: first lay the thermal insulation layer, then install the roof panel (in some projects, a layer of steel mesh is laid under the insulation layer to prevent the insulation layer from falling off, which mainly depends on the insulation layer level). The main quality control: the roof is mainly waterproof, so it is necessary to see the overlapping of boards and boards, the nailing situation, whether the glue coating is full or not, and the gluing place should be wiped clean,The coating on the surface of the plate should not be damaged to prevent rust.

 　　4Wall maintenance and installation: mainly wall insulation layer and wall panel installation.Main quality control: the wall is mainly a beautiful problem, and a window waterproof problem.There is also the problem of installation deviation.For example, the bottom should be flat, the whole plane should be flat, and the flatness deviation between plates should meet the requirements.

 　　5Detail structure: it mainly includes some trimming installation, such as corner between roof and wall, corner of wall, flashing board between wall panel and brick wall, trimming of door and window, etc.Main quality control: detail structure is the last link, and also one of the main aesthetic projects, so horizontal and vertical is the most basic.Some deviations can be seen in the code for acceptance of construction quality of steel structure engineering (GB 50205-2001) and code for acceptance of construction quality of roof engineering (GB 50207-2002).

 Hongjishunda Steel Structure Co., Ltd. is engaged in steel structure engineering, construction engineering, steel member processing and export, steel structure workshop construction design and other types of engineering.Hongjishunda steel structure is a company with more than ten years of steel structure engineering experience. It is a set of steel structure design, processing, installation, maintenance, anti-corrosion, and other aspects in one, to provide you with one-stop construction services.Professionals to do professional work has always been the purpose of three-dimensional, will be able to build high-quality building steel structure engineering.
